1/2-Inch Drive 12-Point Short Hand Socket

Brief Overview

This series of 1/2-inch drive 12-point short hand sockets delivers the precision and durability your shop needs for systematic fastener access. The 12-point design engages fastener heads more efficiently than traditional 6-point geometry, reducing rounding and cam-out on precision work. Available in a continuous 8-38mm size range, these sockets support everything from delicate assembly tasks to heavy-duty automotive applications. If your team also works with 6-point fasteners, we offer matching 6-point short sockets to cover the full spectrum of fastening standards.

Key Features

• 12-Point Drive Design: Engages fasteners at 30° angles, minimizing corner damage and enabling faster socket placement
• Short Socket Profile: Compact 38-42mm length reduces interference in tight engine bays and restricted access areas
• Chrome-Plated Steel Construction: Durable satin finish resists corrosion and wear; embossed size/drive markings remain legible after extended use
• Knurled Grip Ring: Textured outer sleeve near the drive end improves grip and handling, especially with gloved hands
• Chamfered Open End: Beveled rim guides fasteners smoothly into the socket, preventing edge damage during initial engagement
• Continuous Size Coverage: Uninterrupted 8-38mm range eliminates common gaps in socket sets

Business Advantages

For Distributors & Shop Owners:

• High Turnover: 12-point sockets appeal to shops that emphasize precision and speed; this design is increasingly standard in modern fleet maintenance
• System Completeness: The continuous 8mm–38mm range means customers buy the full set rather than sourcing individual sizes elsewhere
• Professional Perception: Chrome-plated finish and precision engineering position this tool as a premium alternative to budget alternatives, justifying margin and supporting repeat orders
• Complementary Sales: Pair with 6-point variants to offer complete fastening solutions and increase basket size

Technical Specifications

Item Code	Size (mm)	D1 (mm)	D2 (mm)	T (mm)	L (mm)
524208	8	13.2	22	12	38
524209	9	14.2	22	12	38
524210	10	15.2	22	12	38
524211	11	16.4	22	12	38
524212	12	17.7	22	12	38
524213	13	18.9	22	12	38
524214	14	20.2	22	12	38
524215	15	21.4	21	12	38
524216	16	22	21	12	38
524217	17	23.9	22	12	38
524219	19	28	23	14	38
524221	21	32	25	14	38
524224	24	36	28	16	38
524227	27	40	30	18	42
524230	30	42	34	22	44
524232	32	42	36	22	44
524233	33	42	36	22	44
524234	34	42	36	22	44
524235	35	42	36	22	44
524236	36	48	42	22	46
524238	38	48	42	22	46

Notes on Specifications:

• D1: Socket wall thickness at the open end (determines contact surface with fastener)
• D2: Maximum outer diameter at the socket body (clearance consideration for tight spaces)
• T: Wall thickness at the drive end (structural strength indicator)
• L: Overall length from open end to drive recess

Typical Applications

• Precision Assembly: Electronics, small engines, or instrumentation where corner damage is unacceptable
• Fleet Maintenance: Modern vehicles with mixed fastener standards requiring both 6-point and 12-point capability
• Restricted Access Work: Engine bays, transmissions, and suspension assemblies where socket length directly impacts usability
• High-Speed Production: Assembly shops where faster socket engagement (30° vs. 60° engagement) reduces cycle time

Why Choose 12-Point Geometry?

The 12-point design is not simply a marketing variation—it offers measurable mechanical advantages. By engaging fastener heads at 30° angles rather than 60°, these sockets reduce rounding risk on worn or softer fasteners and allow faster initial positioning. The trade-off is that 12-point sockets are slightly less suitable for stripped fasteners (where deeper 6-point engagement may be preferred). A complete shop inventory includes both types.

Call to Value

Order the complete 8-38mm range to ensure your shop is never caught without the right socket size. Bulk ordering qualifies for tiered pricing and faster fulfillment. Contact your account manager for volume discounts and delivery timelines.
