1/4-Inch Drive 6-Point Short Hand Socket, 4mm to 14mm
Precision 6-point short hand sockets in 4mm–14mm sizes for 1/4-inch drive, ideal for compact work spaces and precision fastening.
Request QuoteDescription
1/4-Inch Drive 6-Point Short Hand Socket, 4mm to 14mm
Brief Overview
This 6-point short hand socket delivers precise, reliable fastening for applications demanding accuracy in confined spaces. The compact 25mm body length positions it as an essential complement to any professional toolkit, whether you're stocking individual mechanics or building complete socket sets. Cross-reference our full lineup of precision hand-drive sockets to maximize your reseller portfolio.
Key Features
- 6-Point Hex Design: Reduces fastener rounding and cam-out during hand operation; ideal for precision work.
- Short Body Profile: 25mm length enables access in tight spaces where standard sockets cannot reach.
- Knurled Grip Band: Mid-body knurling improves finger control and reduces hand fatigue during manual turning.
- Satin Chrome Plating: Corrosion-resistant finish withstands shop humidity and general handling without degradation.
- Size Range 4mm–14mm: Fourteen individual sizes cover fastener specifications from M4 to M14, supporting diverse assembly and maintenance tasks.
- 1/4-Inch Square Drive: Industry-standard drive connection; compatible with all 1/4" drive tools and ratchet handles.
Technical Specifications
| Size (mm) | D1 (mm) | D2 (mm) | Depth T (mm) | Overall Length (mm) | Item Code |
|---|---|---|---|---|---|
| 4 | 6.8 | 11.9 | 5 | 25 | 522604 |
| 4.5 | 7.1 | 11.9 | 5 | 25 | 522645 |
| 5 | 8.0 | 11.9 | 5 | 25 | 522605 |
| 5.5 | 8.3 | 11.9 | 5 | 25 | 522655 |
| 6 | 9.3 | 11.9 | 5 | 25 | 522606 |
| 7 | 10.5 | 11.9 | 5 | 25 | 522607 |
| 8 | 11.9 | 11.9 | 5 | 25 | 522608 |
| 9 | 13.0 | 13.0 | 8 | 25 | 522609 |
| 10 | 14.0 | 14.0 | 8 | 25 | 522610 |
| 11 | 15.9 | 15.9 | 8 | 25 | 522611 |
| 12 | 16.9 | 16.9 | 10 | 25 | 522612 |
| 13 | 17.8 | 17.8 | 10 | 25 | 522613 |
| 14 | 19.6 | 19.6 | 10 | 25 | 522614 |
Business Advantages for Resellers
- High Turnover Item: Hand sockets are consumable replacements in professional shops; customers regularly replenish worn or lost units.
- Multi-Size Portfolio: Offer sockets individually or bundle complementary sizes to increase average transaction value.
- Mechanic Retention: Stocking reliable, compact 6-point sockets keeps customers returning for maintenance restocks.
- Margin-Friendly: Lower per-unit cost enables competitive pricing while maintaining healthy margins on bulk orders.
- Minimal Inventory Complexity: Fourteen SKUs remain manageable without requiring extensive warehouse space.
Why This Socket Stands Out
The 6-point geometry is a mechanical advantage: it contacts the fastener at six flat surfaces rather than twelve, concentrating grip force and reducing the rounding that occurs with 12-point sockets under manual pressure. For work requiring hand control—electronics assembly, precision machinery, or delicate fasteners—this socket prevents costly damage to bolt heads.
The short 25mm body is purpose-built for confined assembly spaces: engine compartments, control panel interiors, or tight machinery access points where a standard socket cannot fit. Mechanics recognize this immediately and specify short sockets when space is limited.
Reseller Call to Action
Order in bulk by size or build mixed-size assortments to match your customer base. Stock the most-requested sizes (8mm, 10mm, 12mm) as fast movers; less-common sizes (4.5mm, 5.5mm) support specialist customers and differentiate your offering. Pair these sockets with additional drive-size options to create a comprehensive hand-socket solution for your distributor network.
