1/4-Inch Drive E-Type Short Hand Socket, E4 to E12 Sizes

Precision E-type short hand sockets for 1/4-inch drive tools, ideal for tight-access fastener work in automotive and electronics assembly.

Request Quote

Description

1/4-Inch Drive E-Type Short Hand Socket, E4 to E12 Sizes

Brief Overview

This 1/4-inch drive E-type short hand socket series delivers precision engagement with external Torx/E-type fasteners across a full range of sizes (E4 through E12). The compact, stubby design makes these sockets essential for confined spaces where standard-length tools cannot fit. Built with chrome-plated tool steel and featuring a knurled grip band for controlled hand operation, these sockets are purpose-built for precision assembly work, electronics repair, and detailed automotive fastening tasks.

For resellers stocking 1/4-inch drive systems, consider pairing these E-type sockets with complementary 6-point hex hand sockets to offer customers a complete fastener solution. For heavier-duty applications, 1/2-inch drive E-type short sockets are also available.

Key Features

  • E-Type (6-Lobed Torx) Profile: Precision internal geometry prevents cam-out and fastener damage
  • Compact Short Design: Reduced overall length (25mm) enables access in tight, confined spaces
  • 1/4-Inch Drive Compatible: Works with all standard 1/4" ratchet handles and power tools
  • Chrome-Plated Finish: Corrosion resistance and professional appearance
  • Knurled Grip Band: Textured midsection provides secure hand control without slipping
  • Eight Sizes Available: E4, E5, E6, E7, E8, E10, E11, E12 to cover most E-type fastener applications

Why Resellers Choose This Product

High-Margin Consumable Demand: E-type fasteners are becoming increasingly common in electronics, automotive electronics, and precision assembly—creating recurring customer demand for replacement sockets.

Complete Set Selling Opportunity: The eight-size range allows you to bundle or sell as a graduated set, increasing average transaction value and customer lock-in.

Tight-Access Niche: The short design fills a specific gap in customer tool kits. Many professionals lack proper E-type sockets for confined spaces, making these a high-demand specialty item.

Quality Perception: Chrome plating and precise lobing signal professional-grade quality, allowing you to position these as premium tools rather than budget alternatives.

Technical Specifications

Size Fastener OD (D1, mm) Body OD (D2, mm) Lobed Depth (T, mm) Overall Length (L, mm)
E4 6.2 12 5 25
E5 7.2 12 5 25
E6 8.5 12 5 25
E7 9.2 12 6 25
E8 10.2 12 7 25
E10 12 14 10 25
E11 12.2 14 11 25
E12 14.5 14 14 25

Material: Chrome-plated tool steel
Drive Size: 1/4 inch
Finish: Matte chrome plating with engraved product identification
Design Type: Short hand socket (not impact-rated)

Application Notes

These sockets are designed for precision hand-tool work and light-duty power tool applications. They excel in electronics assembly, small-engine repair, precision automotive work (ECU connectors, sensor fasteners), and detailed instrument servicing. The short length specifically addresses the challenge of reaching fasteners in recessed cavities, tight panel gaps, and compact assemblies where standard-length sockets cannot operate.

Call to Value

Stock this range as a specialist offering in your catalog. The eight sizes, compact design, and growing prevalence of E-type fasteners in modern products create a reliable margin opportunity. Customers working in electronics, automotive precision work, and assembly will recognize these as essential tools they cannot easily source elsewhere—making them a key differentiator for your business.
