1/4-Inch Drive E-Type Short Hand Socket

Brief Overview

The 1/4-inch drive E-type short hand socket is purpose-built for accessing and turning Torx-variant fasteners in confined spaces where standard hex sockets won't fit. The six-lobed E-profile design provides secure engagement with minimal cam-out risk, making these sockets essential for precision automotive and electronics assembly work. Whether you're building a reseller inventory or stocking your own shop, these compact tools deliver professional reliability at every torque application. For shops working with larger fasteners, we also offer 1/2-inch E-type short sockets and traditional 6-point hex short sockets to round out your socket collection.

Key Features

• E-Type Multi-Lobed Profile: Six-rounded-lobe design for positive engagement with Torx and Torx-variant fasteners
• Compact Short Design: 25mm length allows access in tight assembly areas and recessed fastener locations
• Knurled Grip Ring: Mid-body texturing provides secure hand grip even in high-oil or high-humidity environments
• Chrome Plated Finish: Durable satin/chrome plating resists corrosion and maintains professional appearance across service cycles
• Eight Size Options: E4 through E12, covering 6.2mm to 14.5mm engagement diameters
• 1/4-Inch Drive Compatible: Direct compatibility with standard 1/4-inch drive ratchets, extensions, and torque wrenches

Size Range & Specifications

Part Number	Size	D1 (mm)	D2 (mm)	Wall Thickness (mm)	Length (mm)
22604	E4	6.2	12	5	25
22605	E5	7.2	12	5	25
22606	E6	8.5	12	5	25
22607	E7	9.2	12	6	25
22608	E8	10.2	12	7	25
22610	E10	12	14	10	25
22611	E11	12.2	14	11	25
22612	E12	14.5	14	14	25

Why This Socket Set Matters for Your Business

Precision Fastener Market: E-type profiles are increasingly common in automotive electronics, HVAC assembly, and medical device manufacturing. By stocking these sizes, you're positioned to serve shops that work with modern fastener standards.

Compact Design Advantage: The 25mm short length addresses a real pain point—standard sockets are too long for recessed or tight-access fastening. This creates a reason for customers to buy additional sockets rather than adapt their existing inventory.

Bulk Order Potential: Eight individual sizes allow customers to customize their order by application (e.g., buy E4–E8 for electronics, E10–E12 for automotive). This drives higher average order values and repeat purchasing.

Durability = Low Return Rate: Chrome-plated steel construction and robust wall thickness mean these sockets survive shop abuse. Fewer comebacks, stronger customer relationships.

Technical Advantages

• Positive Engagement: The multi-lobed E-profile eliminates the "floating fit" problem common with undersized hex sockets, reducing fastener damage and operator frustration.
• Graduated Wall Thickness: Larger sizes (E10–E12) feature thicker walls to handle real-world torque loads without deformation.
• Professional Finish: Satin chrome plating balances corrosion resistance with aesthetic appeal—these look professional in any shop or mobile service unit.

Call to Value

Stock these sockets as a targeted upsell to shops transitioning to modern fastener standards. The combination of tight access capability and secure engagement makes E-type sockets a productivity gain that justifies their cost. Order in bulk to support seasonal demand cycles and establish your company as a trusted source for precision hand tools.
