3-Ton Pneumatic Air Bag Jack with Adjustable Height and Dual Control Valves

Brief Overview

This 3-ton pneumatic air bag jack delivers reliable, controlled lifting for automotive service shops, fleet maintenance facilities, and professional garages. Engineered with reinforced rubber bellows and dual inlet/outlet control valves, it provides smooth, predictable height adjustment from 145mm to 400mm. The design prioritizes operator safety and vehicle protection—ideal as a primary lifting solution or complement to heavy-duty jack stands for secure load support.

Key Features

• Dual Control Valve System: Independent inlet and outlet controls enable precise height adjustment and smooth lowering
• Reinforced Rubber Bellows: Three stacked, grid-textured air cushions resist deformation and extend service life under repeated cycles
• Adjustable Lift Range: 145mm minimum to 400mm maximum height accommodates most vehicle chassis clearances
• Safety Valve: Overpressure protection prevents bellows damage and operator injury
• Stability Guide Sleeves: Vertical metal retainers prevent lateral movement and tilt during lifting
• Integrated Wheels & Stands: Two-wheel mobile base allows easy repositioning; integrated stands ensure stable parking
• Large Contact Pad: 270mm rubber saddle diameter distributes load evenly, protecting vehicle bodywork

Business Advantages for Resellers

High-Volume Appeal: Air bag jacks are consumable-adjacent equipment—shops require regular rotation as bellows age. This positions your operation as a reliable source for replacement units.

Lower Price Point, High Margin: Pneumatic air jacks command lower per-unit cost than hydraulic alternatives, enabling competitive bulk pricing while maintaining healthy margins.

Essential Complement: Pairs naturally with 3-ton jack stands and 5-ton air bag jacks for tiered inventory—serve shops of all sizes.

Durable, Repairable Design: Rubber bellows are field-replaceable; metal frame and valves rarely fail. Customers return for service components, not replacements.

Technical Specifications

Specification	Value
Maximum Load Capacity	3,000 kg (3 tons)
Minimum Lifting Height	145 mm
Maximum Lifting Height	400 mm
Rubber Saddle Diameter	270 mm
Operating Pressure Range	6–12 bar
Control System	Dual inlet/outlet valves with safety release
Bellows Construction	Reinforced rubber (3-stage stack)
Base Configuration	Mobile wheels + vertical guide sleeves
Connection	Standard pneumatic hose coupling

Why This Matters for Your Customers

Mechanics trust air bag jacks for steady, low-noise lifting—no pump noise, no fluid leaks. The 145–400mm range fits most sedan and light truck work without requiring multiple units. The dual-valve design prevents sudden drops, critical for operator confidence in busy shops.

The reinforced bellows and large contact pad reduce callout claims from vehicle damage. Shops running 4–6 lifts per day see these units last 2–3 years with proper maintenance—strong durability story for your sales pitch.

Call to Value

Stock this 3-ton pneumatic jack as your core lifting solution. Pair it with heavy-duty jack stands for complete load support during service work. Order in volume for fleet maintenance contracts and independent shop networks—margins and turnover justify bulk investment.
