E6013 MMA Welding Electrode, 2.5mm Diameter, 300mm Length, 5kg Box

Brief Overview

This E6013 flux-coated electrode delivers reliable performance across general-purpose welding applications. Classified to AWS A5.1 ER6013 and GB/T 5117 ER4313 J421 standards, these electrodes are engineered for unalloyed and low-alloy steel structures. The straightforward chemistry and proven arc characteristics make this a go-to consumable for shops stocking MMA welding equipment or operating mixed welding environments that need dependable all-position capability.

Key Features

• All-Position Capability: Works seamlessly in overhead, vertical, and horizontal positions with both AC and DC (-Pol) current
• Excellent Arc Stability: Superior ignition and reignition properties reduce downtime and improve operator productivity
• Easy Slag Removal: The formed slag comes away cleanly, minimizing cleanup time between passes
• Dual Current Compatibility: Operates on alternating and direct current, providing flexibility across different welding machine types
• Consistent Coating: Uniform gray flux coating ensures predictable performance rod-to-rod

Technical Specifications

Specification	Value
Electrode Type	E6013 (AWS A5.1 / GB/T 5117 ER4313 J421)
Diameter	2.5 mm
Length	300 mm
Box Weight	5 kg
Recommended Current (AC/DC)	90–120 A
Welding Position	All Positions
Current Type	AC or DC (-)

Chemical Composition (%)

Element	Content
Carbon (C)	0.11
Manganese (Mn)	0.38
Silicon (Si)	0.30
Phosphorus (P)	0.02
Sulfur (S)	0.002
Nickel (Ni)	0.10
Iron (Fe)	Balance
Others	0.50

Recommended Applications

• Steel Structures: General fabrication and structural assembly work
• Vehicle Manufacturing & Repair: Bodywork and frame welding
• Shipbuilding: Hull sections and structural components
• Machinery & Equipment: General machine assembly and repairs
• Pressure Vessels & Boilers: Reliable performance on container and boiler construction
• Field Welding: Portable and versatile for on-site repairs and maintenance

Business Advantages for Resellers

High Stock Turnover: E6013 electrodes remain the industry standard for general-purpose MMA work. Shops running older equipment or cost-conscious operators consistently reorder this grade, ensuring predictable inventory movement.

Broad Customer Base: This consumable appeals to small independent repair shops, agricultural equipment dealers, fabrication facilities, and maintenance operations—diverse channels mean consistent demand.

Complementary Ecosystem: Stock these alongside portable inverter welders or electrode storage solutions to build a complete welding package offering. Operators buying equipment naturally purchase consumables.

Minimal Technical Support: The proven, straightforward chemistry reduces customer complaints and warranty issues, protecting your margin and reputation.

Why This Specification Works

The 2.5mm diameter and 90–120A current range position this electrode perfectly for light-to-medium fabrication work—the sweet spot for general repair shops and smaller fabrication operations. The 300mm length balances electrode efficiency (minimal stub loss) with operator comfort in extended welding sessions. The 5kg box is the standard industrial pack size, familiar to all buyers and easy to stock in bulk.

---

Ready to source a reliable, high-turnover welding consumable? This E6013 electrode delivers the proven performance your customers expect, backed by international standards and field-tested reliability. Order in bulk for consistent margins and customer satisfaction.
