Ford 1.6 Ti-VCT Engine Timing Tool Kit – Camshaft & Crankshaft Locking Set

Brief Overview

This is a purpose-built timing tool kit designed specifically for Ford 1.6 Ti-VCT Duratec engines, covering all essential components needed to safely lock the camshaft, crankshaft, and flywheel during timing belt service. The kit includes precision-machined locking plates, alignment pins, and spacer adapters—all housed in a protective carry case for shop organization. Beyond Ford applications, the camshaft and crankshaft pins are compatible with numerous petrol and diesel Ford engines, as well as select Volvo models from 2010 onwards, making this a valuable cross-application toolkit. If you service multiple Ford engine families, consider pairing this with our specialized EcoBoost timing tools or our comprehensive Volvo and Ford timing kit for broader engine coverage.

Key Features

• Complete Locking System: Camshaft locking plate (X-shaped design), crankshaft alignment pin, and flywheel positioning bracket included
• Multi-Engine Compatibility: Covers Ford 1.6 Ti-VCT/SCTi plus 20+ additional Ford and Volvo engine variants (see full compatibility list below)
• Precision Machining: Black-coated steel tools with white reference markings; silver-finished metal pins for corrosion resistance
• Protective Carry Case: Blue hard plastic case with molded cavities and snap latches; includes yellow instruction/warning label on lid
• Easy Shop Storage: Organized case design keeps all components together and prevents loss during service intervals

Technical Specifications

Component	Description	Application
Camshaft Locking Plate	Black X-shaped locking cross with white printed reference markings	Ford 1.6 Ti-VCT and compatible engines
Crankshaft Alignment Pin	Knurled silver metal pin for precise crankshaft positioning	Timing synchronization
Flywheel Positioning Bracket	T-shaped metal bracket with locating stud and spring retainer	Flywheel lock-down during service
Spacer/Adapter	Black rectangular multi-notch adapter with machined cutouts	Camshaft and crankshaft engagement
Case	Blue hard plastic with snap latches and molded tool cavities	Storage, transport, and shop organization

Engine Compatibility

Ford Applications: B-MAX (2010+), C-MAX (2003–2012), Fiesta (2013+), Galaxy (2010+), Focus (2004–2015), Grand C-MAX (2010+), Kuga (2013+), Mondeo (2010+), S-MAX (2010+), Tourneo Connect (2013+), Transit Connect (2013+)

Volvo Applications: S60 Cross Country T4 (2011–2015), S80 GTDi T3 (2010–2015), V40 GTDi T4 (2012–2015), V60 GTDi T4F (2011–2015), V70 T2/T3/T4 (2010–2015)

Engine Codes Covered: HXJA, HXJB, HXDA, IQDA, IQDB, PNBA, RHBA, SIDA, 1.6Ti-VCT FFV, PNDA, JTWB, JTWA, JTDB, JTDA, JQDB, JQDA, IQJA, B4164T4, B4164T3, B4164T2, B4164T, JQMA, JQMB, JTMA, XTDA, MUDA, JTJA, JTBA, JTBB, KGBA, JQGA

Business Advantages for Resellers

• High Demand Service Category: Timing belt service remains a core shop procedure with predictable repeat business; this kit addresses one of the most popular Ford powertrains in European and global service markets
• Broad Compatibility = Larger Customer Base: Coverage of 20+ engine variants and Volvo applications means higher volume potential per single SKU investment
• Complete Solution = Higher Margins: Customers requiring timing service cannot work without proper locking tools; offering the complete kit eliminates part-number chasing and builds customer loyalty
• Established Market Category: Timing tool kits have proven sell-through; this addresses a recognized gap for 1.6 Ti-VCT specialists
• Professional Presentation: Blue carry case with organized layout signals quality to end customers and supports premium positioning

Why This Kit Matters for Your Shop

Timing belt replacement on Ford 1.6 Ti-VCT engines demands precise camshaft and crankshaft locking to prevent valve-to-piston contact and catastrophic engine damage. Using OEM-equivalent locking pins and adapters—rather than improvised methods—reduces comebacks and liability. The multi-notch spacer adapter ensures correct engagement with engine timing points, while the spring-loaded flywheel bracket guarantees repeatable alignment across multiple services. This is a professional-grade, not a compromise solution.

Call to Action

Stock this kit for Ford 1.6 Ti-VCT and Duratec services. With coverage extending to 20+ related engine variants, a single investment covers significant workshop demand. Bulk order pricing available for distributors and shop chains.
