HVLP Gravity-Feed Paint Spray Gun, 1.4mm Nozzle, 0.6L Tank

Brief Overview

This is a high-volume, low-pressure (HVLP) gravity-feed spray gun designed for precise automotive refinishing, furniture coating, and detailed paint application work. The 1.4mm nozzle delivers controlled, fine atomization at low working pressure (3 Bar), minimizing overspray and material waste—a critical advantage for professional shops managing coating costs. The compact 0.6L gravity tank keeps the tool lightweight and maneuverable, while the interchangeable nozzle system allows quick adaptation to different coating viscosities. Pair this with sealant application tools to offer your customers a complete finishing solution for both paint and protective coating work.

Key Features

• Gravity-Feed Tank (0.6L): Lightweight design reduces fatigue during extended spraying sessions; fast refill cycles for continuous production.
• 1.4mm Precision Nozzle: Fine atomization ideal for clear coats, base coats, and detailed finish work; switchable nozzles accommodate different fluid types.
• Low Working Pressure (3 Bar): Reduces overspray by up to 25% compared to conventional spray guns, directly lowering material costs and waste.
• Adjustable Pattern & Flow Controls: Front-body knobs enable quick tuning for fan width and fluid delivery without tool changes.
• Durable Metal Construction: Polished metal trigger mechanism and fittings withstand daily professional use.
• Complete Accessories Kit: Includes spray filter, 2 replacement brushes, and 2 wrenches for rapid nozzle/cap swaps—minimizing downtime.
• 1/4″ Air Inlet (10mm Supply Hose): Standard industrial connection; compatible with most compressor setups.

Business Advantages for Resellers

• Lower Total Cost of Ownership: The 3 Bar pressure and fine nozzle reduce paint consumption by 15-20% per job compared to standard spray guns—your customers save money per application.
• Compact, Lightweight Design: Easy to stock, light enough for one-handed operation during extended shifts, reducing customer fatigue complaints.
• Fast Turnover: Interchangeable nozzles and included wrenches eliminate service delays; gravity feed means no siphon tube cleaning downtime.
• Margin-Friendly Accessory Ecosystem: Filter replacements, nozzles, and tank seals create ongoing revenue streams from established customers.
• Professional-Grade Reliability: Metal construction and precision nozzle design justify premium pricing and build customer loyalty for repeat orders.

Technical Specifications

Specification	Value
Nozzle Diameter	1.4mm
Tank Capacity	0.6L (gravity feed)
Air Consumption	300L/min
Working Pressure	3 Bar
Air Inlet Connection	1/4″
Recommended Supply Hose	10mm diameter
Minimum Compressor Requirement	350–400L capacity, 2.2–3kW power, 100L/min output

Operational Notes

This tool is optimized for HVLP finishing work. The 300L/min air consumption requires a mid-sized compressor with adequate reserve capacity (minimum 350L tank recommended) to maintain stable pressure during continuous spraying. The 3 Bar operating pressure is significantly lower than conventional spray guns—ensure your customers understand that this is intentional for reduced overspray and material waste, not a limitation.

The 0.6L gravity tank is ideal for detailed work but requires frequent refilling for large-area coverage. For high-volume production runs, consider recommending a siphon-feed conversion or a larger HVLP model from your catalog.

---

Ready to Order? Stock this HVLP spray gun to serve customers in automotive refinishing, furniture coating, and detail work. Its precision nozzle and low-waste design make it a natural upsell to shops upgrading from conventional spray equipment.
