INFARE Paint Drying Lamp 6000W – Professional Infrared Varnish Curing System

Brief Overview

This is a professional-grade infrared paint drying solution designed for high-volume automotive refinish shops and industrial coating operations. The 6000W output delivers powerful short-wave infrared radiation that penetrates paint and varnish layers, initiating curing directly at the substrate without heating ambient air. The mobile unit with six quartz lamp heads mounted on an adjustable arm offers flexibility for various panel sizes and body contours. For shops requiring lower power density or different coverage patterns, smaller-capacity infrared curing lamps are also available.

Key Features

• Six quartz infrared lamp heads – Dual-column arrangement with individual reflective housings for concentrated heat delivery
• 6000W total output – Maximum power for heavy-duty production environments and thick coating applications
• Adjustable height control – 0.2 to 2.1 meters for precise positioning over panels and body sections
• Pivotable lamp arm and heads – Individual adjustment knobs and joints allow custom angles and spacing
• Programmable timer – 0 to 99 minutes with visual LED feedback for repeatable cure cycles
• Variable temperature output – 40–75°C working range controlled via multi-switch interface
• Wheeled mobile base – Four swivel casters for easy repositioning within the shop
• Single-phase power – 230V 50/60Hz operation; 27.2A draw (dedicated circuit recommended)
• Optimal working distance – 0.5–0.7 meters for consistent infrared penetration

Why This Matters for Your Shop

Production Efficiency: The 6000W rating cuts cure cycles significantly compared to lower-wattage systems, reducing bottlenecks during peak finishing periods. Shops handling multiple vehicles per shift gain measurable time savings.

Cost Control & Profitability: Infrared-only heating (no air conditioning load) reduces energy waste. The programmable timer eliminates over-curing and material waste, protecting your margin per job.

Flexibility & Durability: Mobile base and adjustable arm accommodate everything from small trim panels to full-body work without repositioning the entire unit. Quartz lamp construction offers long service life and consistent spectral output.

Customer Resale Value: Position this as a premium finishing tool that ensures uniform, rapid curing—a genuine competitive advantage worth premium labor rates to your clientele.

Technical Specifications

Parameter	Value
Power Output	6000W
Power Supply	1-phase, 230V, 50/60Hz
Working Current	27.2A
Lamp Heads	6 × quartz infrared (dual column)
Temperature Range	40–75°C (adjustable)
Timer Range	0–99 minutes
Height Adjustment	0.2–2.1 m
Working Distance	0.5–0.7 m
Base Configuration	Mobile U-frame with swivel casters
Control Interface	Multi-switch panel, LED indicator, rotary timer
Certifications	CE marked

Call to Action

This is a production-level infrared curing system for shops serious about throughput and consistency. Stock this unit for clients handling industrial coatings, automotive refinish, or heavy-duty varnish applications. Pair with entry-level infrared drying solutions for customers with smaller batch volumes or to offer tiered solutions across your product line.

Ready to add premium curing capacity to your distributor lineup?
