1/4-Inch Pneumatic Pistol-Grip Screwdriver, 2000 RPM, 30 Nm Torque

Brief Overview

This 1/4-inch pneumatic screwdriver is engineered for high-speed assembly operations where precision and ergonomic comfort are essential. The pistol-grip design with forward/reverse capability makes it ideal for production environments and shop floors handling repetitive fastening tasks. For shops requiring variable speed control or lower torque applications, lower-speed pneumatic screwdrivers with hex chuck are also available to complement your tool inventory.

Key Features

• High Rotational Speed: 2000 RPM free speed for rapid screw driving without operator fatigue
• Adjustable Clutch System: 0–25 Nm working torque range prevents over-tightening and protects delicate assemblies
• Pistol-Grip Design: Ergonomic rubber grip reduces hand fatigue during extended production runs
• Forward/Reverse Capability: Metal selector lever enables rapid directional changes without tool removal
• Compact Footprint: 207 mm length and 152 mm height allow access to tight assembly spaces
• Light Weight: 0.63 kg (1.38 lb) minimizes operator strain during all-day use
• 1/4-Inch Air Inlet: Standard pneumatic connection compatible with most shop air systems

Business Advantages for Resellers

• High-Volume Production Appeal: The 2000 RPM speed is attractive to assembly shops and manufacturers looking to increase throughput
• Accessible Torque Range: 30 Nm maximum capacity covers general assembly and light fastening work—a sweet spot for industrial OEM resale
• Proven Design: Pistol-grip + adjustable clutch combination is a reliable, field-tested configuration that reduces returns
• Low Air Consumption: 0.9 L/min keeps customer infrastructure costs minimal, improving TCO perception
• Margin-Friendly Category: Pneumatic hand tools maintain consistent resale demand with healthy margins across shop segments

Technical Specifications

Specification	Value
Shank Size	3/8" (9.5 mm)
Maximum Torque	30 Nm (22.1 ft-lb)
Working Torque Range	0–25 Nm (0–18.4 ft-lb)
Bolt Capacity	10 mm (3/8")
Free Speed	2000 RPM
Weight	0.63 kg (1.38 lb)
Noise Level	83 dBA (94 power)
Vibration (a/k)	11.3 m/s² / 1.6 m/s²
Air Consumption	0.9 L/min (1.9 CFM)
Air Inlet	1/4" (6.35 mm)
Overall Length	207 mm
Overall Height	152 mm

Why This Tool Sells

Assembly shops and contract manufacturers know that tool consistency drives productivity. This pneumatic screwdriver delivers predictable speed, controlled torque, and ergonomic comfort—three factors that directly reduce assembly time and operator complaints. At 0.63 kg, it's light enough for all-day use without inducing fatigue-related errors. The adjustable clutch prevents the two most expensive problems in assembly: over-tightening (stripped threads, damaged PCBs, broken fasteners) and under-tightening (returned product, field failures).

Your customers will return for stock replenishment, and they'll recommend it to peers facing the same production pressures.

---

Ready to stock pneumatic assembly solutions? Contact our team for bulk pricing and distributor terms.
