Positive Grip 1/8" and 1/4" Capacity Collet Chuck, 22,000 RPM Pneumatic

Brief Overview

This pneumatic collet chuck delivers precision and control for fine grinding, finishing, and rotary tool applications. The dual-capacity design—accepting both 1/8" (3mm) and 1/4" (6mm) collets—makes it versatile across multiple job types without requiring separate tools. Ball bearing construction ensures durability under continuous shop use, while the safety lever prevents accidental spindle rotation. The rear air exhaust deflection keeps work areas cleaner and safer. For resellers stocking pneumatic accessories, this tool pairs exceptionally well with complementary offerings like high-precision air-powered drills and quick-change bit holders.

Key Features

• Dual-Capacity Collets: Accepts both 1/8" (3mm) and 1/4" (6mm) tools via positive-grip mechanism
• Ball Bearing Construction: Engineered for extended service life and consistent performance
• Safety Lever with Latch: Prevents unintended spindle engagement, critical for operator safety
• Rear Air Exhaust Deflection: Directs exhaust away from the work surface and operator
• Compact Straight Design: 170mm length enables use in confined spaces and detail work
• Complete Kit Included: Supplied with collets, shank stones, nipple, and key wrenches—ready to work out of the box

Business Advantages for Resellers

• High-Velocity Turnover: 22,000 RPM specification attracts professional finishers and precision shops seeking speed without sacrificing control
• Margin-Friendly Accessory: Lower price point than multi-tool systems, yet delivers professional-grade results—ideal for upselling to existing pneumatic tool customers
• Complete Package Deal: Inclusive accessory kit reduces returns and customer support calls; buyers don't need to hunt for compatible collets or wrenches
• Dual-Application Appeal: Serves both general finishing work and precision grinding markets, broadening your customer base
• Proven Reliability: Ball bearing design minimizes warranty claims and builds customer confidence in repeat purchases

Technical Specifications

Specification	Value
Collet Capacity	1/8" (3mm) and 1/4" (6mm)
Free Speed (RPM)	22,000
Overall Length	170 mm
Weight	0.55 kg
Air Inlet Connection	1/4" BSP
Air Consumption	4 CFM (113 L/min)
Construction	Ball bearing spindle with positive-grip collet
Included Accessories	1× 1/8" collet, 5× 1/4" shank stones, 5× 1/8" shank stones, 1× nipple, 2× key wrenches

Operational Context

Best suited for:

• Precision grinding on small components and delicate surfaces
• Finishing work where speed and control are equally critical
• Rotary tool applications in automotive detail, jewelry, and electronics assembly
• Shops with compressed air infrastructure already established (standard 1/4" BSP connection)

The 4 CFM air consumption sits well within typical shop compressor capacity, reducing infrastructure investment for your customers.

Call to Value

Stock this dual-capacity collet chuck as a core item in your pneumatic accessories lineup. The complete kit, professional-grade construction, and versatile capacity range make it an easy recommendation to finish-work specialists and multi-tool shops. Low weight and compact design also support higher inventory density—maximize shelf space efficiency while meeting strong customer demand for precision pneumatic solutions.
