Angled side view of red and black pneumatic die grinder showing 1/4" collet, silver label, rubberized grip and red air-fitting at rear.Side view of pneumatic die grinder showing metal throttle lever with safety tip, red/black housing, vents and stickers.Close-up of die grinder front showing collet opening, internal spindle and retaining features inside the nose.

1/4-Inch Medium Pneumatic Die Grinder, 22,000 RPM Variable Speed

Professional variable-speed die grinder with rubberized body, ideal for deburring, finishing, and precision grinding applications.

Request Quote

Description

1/4-Inch Medium Pneumatic Die Grinder, 22,000 RPM Variable Speed

Brief Overview

This medium-duty pneumatic die grinder delivers 22,000 RPM variable-speed performance in a compact, vibration-dampening design. The rubberized polymer body provides thermal insulation and reduces operator fatigue during extended use—a significant upgrade over traditional all-metal housings. The safety lever throttle and rear exhaust port offer precise speed control and improved ergonomics for detailed finishing work. Pair this grinder with complementary low-noise pneumatic tools or high-speed variants to build a complete finishing station that serves multiple application tiers.

Key Features

  • Variable Speed Control: Adjustable throttle lever for precise RPM management from idle to full 22,000 RPM
  • Polymer-Reinforced Body: Rubberized overmold absorbs vibration and insulates against cold metal housing—reducing operator discomfort and improving control
  • Standard 1/4" Collet: Accepts common carbide burs, mounted stones, mini drum sanders, and polishing attachments
  • Optional Collet Sizes: 6mm, 1/8", and 3mm configurations available for specialized applications
  • Rear Exhaust Design: Directs exhaust away from workpiece and operator
  • Safety Lever Throttle: Hinged metal trigger with safety features and integrated CE/pictogram markings
  • Compact Form Factor: 45mm width enables access to tight work areas
  • 12-Month Warranty: Full manufacturer coverage included

Business Advantages for Resellers

Margin & Turnover: The variable-speed feature appeals to precision shops that need single-tool versatility—reducing customer SKU pressure on your inventory. The rubberized body design is a premium upgrade that justifies higher margins versus basic metal competitors.

Shop Stickiness: Die grinding is a core operation in automotive, aerospace, and moldmaking shops. This tool's ergonomic design and speed control reduce operator complaints, leading to repeat orders and word-of-mouth referrals.

Application Breadth: One grinder handles deburring, flash removal, finishing, and polishing—widening your addressable customer base across job shops, tool & die facilities, and small manufacturing.

Technical Specifications

Specification Value
Collet Size (Standard) 1/4"
Optional Collet Sizes 6mm, 1/8", 3mm
Free Speed 22,000 RPM
Speed Type Variable (Throttle-Controlled)
Air Consumption (Average) 566 L/min (20 CFM)
Air Inlet Connection 1/4" NPT
Body Material Metal with Rubberized Polymer Overmold
Grip Type Molded Rubber Sections with Ventilation Slots
Weight 0.60 kg
Barrel Width 45 mm
Exhaust Direction Rear
Throttle Type Safety Lever (Metal Hinged)
Warranty 12 Months

Application Profile

Ideal for:

  • Deburring cast and machined components
  • Flash removal on molded parts
  • Precision finishing on aerospace components
  • Polishing and honing operations
  • Detail work in confined spaces (compact 45mm profile)
  • Operations requiring variable speed control (finishing vs. aggressive stock removal)

Call to Value

Stock this variable-speed workhorse as a core finishing tool—it bridges precision applications that demand speed adjustment without requiring multiple SKUs. The ergonomic design reduces operator fatigue claims, and the 1/4" standard collet ecosystem ensures strong consumable attach rates through bur and stone sales.
