Right-angle metal die grinder with ribbed body, black throttle lever, blue S logo and black 6mm colletClose-up of die grinder head showing internal bore, threads and air-vanes with black throttle housing beneathTop view of polished die grinder body with stamped WARNING text, circular port, ribbed grip and rear hex air fitting

Right-Angle Pneumatic Die Grinder, 6mm Collet, 20,000 RPM

Compact 90-degree pneumatic die grinder with 6mm collet, ideal for precision grinding in tight spaces and detail work.

Request Quote

Description

Right-Angle Pneumatic Die Grinder, 6mm Collet, 20,000 RPM

Brief Overview

This right-angle pneumatic die grinder delivers precision grinding capability in a compact, ergonomic package designed for detailed work in confined spaces. The 90-degree angled head configuration positions the tool perpendicular to the operator's hand, enabling access to tight corners and interior surfaces where inline grinders cannot reach. With a 6mm collet, it accepts standard grinding stones, burrs, and accessory bits, making it versatile for metalworking, fabrication, and detail finishing tasks. For shops requiring higher speeds or specialized configurations, consider pairing this with a high-speed straight-shaft grinder or a low-speed planetary geared alternative for specific application demands.

Key Features

  • 90-Degree Angled Head: Provides ergonomic access to interior surfaces, corners, and edges without repositioning the workpiece
  • 6mm Collet Compatibility: Accepts standard 6mm grinding stones, burrs, and precision tooling
  • 20,000 RPM Operating Speed: Balanced performance for controlled grinding without excessive vibration
  • Lightweight Design: 0.49 kg (1.08 lb) reduces operator fatigue during extended use
  • Lever-Style Throttle Control: Intuitive hand-operated speed modulation for precision work
  • Low Air Consumption: 2.3 CFM (1.1 L/s) enables use on standard compressed air systems without undersizing compressors
  • Polished Metal Finish: Durable construction with ribbed grip panels for secure handling
  • Safety Latch Mechanism: Prevents accidental tooling ejection during operation

Business Advantages for Resellers

  • Wide Market Appeal: Right-angle die grinders address a specific need that inline models cannot—shops stocking both configurations capture a larger customer base
  • Accessible Price Point: Lower output power (127W) reduces manufacturing costs, allowing competitive wholesale pricing and healthy margins
  • Standard Collet Size: 6mm is a universal standard, simplifying inventory management and cross-selling with common accessory bits
  • Low Barrier to Adoption: Minimal air requirement (2.3 CFM) means compatibility with smaller shop compressors, increasing addressable customer base
  • Durability: Industrial-grade construction withstands regular professional use, reducing warranty claims

Technical Specifications

Specification Value
Collet Size 6mm / 1/4"
Maximum Speed (No Load) 20,000 RPM
Output Power 127W
Weight 0.49 kg (1.08 lb)
Air Consumption (Average) 2.3 CFM / 1.1 L/s
Noise Level 83 dB(A) at tool / 94 dB(A) at power source
Vibration Level 7.4 m/s² (operating) / 1.6 m/s² (handle)
Head Configuration 90-Degree Angled
Throttle Type Lever-Style (Hand-Modulated)
Air Inlet Hexagonal Quick-Connect Fitting

Application Context

This grinder is engineered for precision work requiring angled access—interior polishing of cast parts, deburring inside blind holes, detail grinding on curved surfaces, and finishing work in confined assembly areas. The 20,000 RPM speed sits in the "controlled precision" range, avoiding the aggressive grinding action of higher-speed models while maintaining sufficient power for light to medium material removal.

Closing Statement

Stock this right-angle model as a complementary offering to your inline grinder lineup. It directly addresses customer requests for angled tooling access and fills a distinct market segment. The low air demand and compact weight make it an excellent entry-level choice for smaller shops upgrading their grinding capability.
