Open blue plastic case with short-arm rivet nut tool, silver mandrels, black nosepieces and spanner wrench neatly arranged in molded compartments.Short-arm rivet nut tool with blue handles, black nosepieces, spanner wrench and silver mandrels on white background; brand label on tool head visible.Close view of rivet nut tool head with knurled nose cap and adjustment dial, surrounded by silver threaded mandrels and black nosepieces.Rivet nut hand tool with blue grips, row of black nosepieces, multi-fit spanner and silver mandrels on white background, detail of tool head and fittings.

Short-Arm Threaded Riv Nut Tool Set, M3–M10, Chrome Vanadium, 320mm

Professional rivet nut insertion tool set for M3–M10 applications across aluminium, steel, and stainless steel. Includes six nozzles and carry case.

Request Quote

Description

Short-Arm Threaded Riv Nut Tool Set

Overview

This is a purpose-built hand tool for setting threaded rivet nuts in sheet metal and structural assemblies. The 320mm short-arm design balances leverage with workspace accessibility—ideal for confined areas where longer tools create friction losses. The set covers the most common industrial sizes (M3, M4, M5, M6, M8, M10), making it suitable for automotive sub-assembly, HVAC ducting, aerospace panel work, and general metal fabrication. For higher-volume production or larger sizes, consider pairing this with a long-arm rivet nut insertion tool or a pneumatic nut riveter for M4–M12 range work.

Key Features

  • Chrome Vanadium forged arms – Resistant to fatigue and flexing under cyclic loading; maintains dimensional stability over thousands of cycles
  • Wear-resistant nozzles – Hardened steel nose pieces prevent galling and extend tool life across repeated size changes
  • Double-handle ergonomic design – Textured blue grips reduce hand fatigue during repetitive insertion; balanced lever geometry minimizes operator strain
  • Indexed adjustment dial – Gear-style selector ensures precise mandrel engagement; prevents cross-threading and inconsistent seating
  • Six interchangeable mandrels and nozzles – M3, M4, M5, M6, M8, M10mm coverage handles 95% of standard threaded riv nut applications
  • Knurled nose cap – Secures mandrel and nozzle assembly; prevents accidental disassembly during use
  • Supplied spanner wrench – Enables quick nozzle changes and on-site mandrel adjustment
  • Hard-shell carry case with molded storage – Protects components during transport; reduces lost-part incidents and maintains inventory control

Business Advantages for Distributors

  • High-margin consumable accessory category – Nozzles and mandrels require periodic replacement; repeat orders from end-users
  • Complete essential set – No additional nozzle purchases required for common industrial sizes; reduces customer contact friction and increases first-purchase satisfaction
  • Compact footprint – 320mm length fits standard tool racks and van storage; appeals to mobile technicians and small shops with limited bench space
  • Brand-neutral white-label positioning – Rebranding ready for distributor house brands; supports margin expansion without OEM restrictions
  • Cross-sell opportunity – Perfect entry-level tool for shops expanding into light structural assembly; leads to upsells for pneumatic or hydraulic systems on larger jobs

Technical Specifications

Specification Detail
Arm Length 320mm (short reach)
Material – Arms Chrome Vanadium (Cr-V) forged steel
Material – Nozzles Hardened steel (wear-resistant)
Nozzle Sizes Included M3, M4, M5, M6, M8, M10mm
Compatible Materials Aluminium, steel, stainless steel
Handle Type Dual-lever ergonomic with textured grip
Adjustment Mechanism Indexed gear dial
Accessories Included 6 mandrels, 6 nozzles, spanner wrench, carry case
Case Type Hard-shell plastic with molded inserts and handle

Why Stock This Set

Threaded rivet nut insertion is a non-negotiable process in metal fabrication, HVAC assembly, and automotive sub-tier manufacturing. This tool set delivers the precision and durability required for high-volume work without the capital investment of pneumatic or hydraulic systems. The compact 320mm arm design outperforms longer tools in tight assembly spaces—a competitive edge for shops handling panel and bracket work. Stock it as a core hand tool offering; the repeat nozzle business alone justifies shelf allocation.
