Straight Pneumatic Screwdriver with Push-Start System, 2 Nm Auto-Shutoff

Brief Overview

This is a straight-barrel pneumatic screwdriver engineered for precision fastening applications where torque control and repeatability matter. The integrated push-start system eliminates accidental triggering, while the automatic shutoff at 2 Nm delivers consistent, operator-independent torque application—critical for delicate assembly, electronics work, or anywhere over-tightening risks component damage.

The special air exhaust system reduces noise and environmental impact, making this tool suitable for facilities with tighter operational standards. If your shop handles higher-torque work, consider pairing this with higher-capacity alternatives to cover your full torque spectrum.

---

Key Features

• Push-Start System: Manual trigger engagement—no accidental activation, safer for hand-held precision work
• Automatic Shutoff at 2 Nm: Tool stops firing when target torque is reached; repeatable, consistent results without operator judgment
• Straight Barrel Design: Inline orientation for confined spaces, tight corners, and overhead assembly
• 1/4-Inch Hex Chuck: Accepts standard hex-shank bits; interchangeable for Phillips, slotted, and hex fasteners
• Detachable Rubber Grip Sleeve: Removable blue ribbed sleeve for ergonomic control or quick swaps in high-volume lines
• Torque Adjustment Collars: Four color-coded plastic collars (green, orange, blue, pink) for quick visual identification of torque preset settings across multiple units or stations
• Eco-Friendly Exhaust System (O.E. variant): Reduced noise and air discharge; meets tighter environmental compliance for indoor assembly environments
• Hanging Retention Clip: Black wire clip for tool organization and quick-access wall mounting
• Brass Air Adapter: Barbed fitting for secure hose connection; minimizes air leakage at pressure points

---

Business Advantages for Resellers

• Niche Market Positioning: The 2 Nm shutoff targets precision assembly—PCB work, medical device assembly, electronics—where over-torque rejection is a selling point
• Repeatable Quality: Auto-shutoff eliminates training variability; shops reduce scrap from over-tightened fasteners
• Modular Accessory Appeal: Color-coded collars and detachable grip sleeve create upsell opportunities for replacement parts and bulk handle kits
• Eco-Variant Advantage: The O.E. (exhaust-optimized) model appeals to ISO 14001 certified facilities and cleanroom operations—higher margin segment
• Tool Fleet Standardization: The straight-barrel form factor complements other precision pneumatic models in your portfolio, enabling shops to build modular torque-controlled assembly stations

---

Technical Specifications

Specification	Detail
Torque Setting	2 Nm (automatic shutoff)
Chuck Type	1/4-Inch Hex
Activation	Push-Start (manual trigger)
Barrel Design	Straight (inline)
Handle Material	Rubberized composite with detachable grip sleeve
Torque Preset Collars	4 color-coded (green, orange, blue, pink)
Air Connection	Brass barbed adapter (standard hose-barb)
Special Features	Eco-friendly air exhaust system (O.E. variant)
Retention/Hanging	Wire clip integrated into rear housing
Included Accessories	Detachable blue grip sleeve, color-coded collars, screwdriver bits (hex-shank), brass air adapter

---

Application Context

This tool is built for controlled-torque assembly environments where precision and repeatability are non-negotiable:

• Electronics & PCB Assembly: Mounting components on circuit boards without risk of crushing traces or connectors
• Medical Device Manufacturing: Fastening where over-torque voids calibration or damages sensitive components
• Precision Mechanical Assembly: Small-engine work, optical equipment, instrumentation
• High-Volume, Low-Torque Lines: Automotive interior trim, switch assembly, connector fastening
• Cleanroom & Controlled Environments: The eco-exhaust variant minimizes particulate discharge

Not suitable for: High-torque applications (>2 Nm), impact driving, or heavy-duty fastening—these demands call for impact wrenches or higher-torque pneumatic drivers.

---

Reseller Positioning

Position this as a precision-class pneumatic fastener—not a general-purpose tool. Your buyers are quality-conscious manufacturers, assembly contract shops, and OEM suppliers where scrap reduction and repeatability justify the investment. The auto-shutoff feature is your key differentiator: it removes operator error from the equation, directly translating to fewer warranty claims and faster assembly cycles.

Bundle with color-coded collision rings and replacement grip sleeves to boost attach rates on initial orders.
