Timing & Locking Tool Set for VAG AXU, BAG, BKG Engines

Overview

This specialized timing and locking tool set is engineered for precise camshaft timing adjustment on VAG group petrol engines. Whether you're performing timing belt replacements, timing chain service, or major engine repairs, this kit provides the critical tools needed to lock the crankshaft and camshaft in the correct TDC (Top Dead Center) position—essential for proper engine synchronization and preventing costly alignment errors.

If your shop also services VAG diesel engines, consider pairing this with diesel engine locking tools for complete coverage across your service range.

Key Components & Features

• Camshaft Locking Plate – Two-disc metal design with central bracket for secure camshaft positioning during adjustment
• TDC Dial Indicator – Precision white-faced gauge with graduated scale for accurate crankshaft positioning to Top Dead Center
• Alignment/Holding Bar – Long orange-handled tool with metal tip and engraved positioning marks for reliable handling and precise engagement
• Alignment Pins (3 pieces) – Varying lengths in hardened metal for engine-specific locking points
• Retaining Clip – Secures components during storage and transport
• T-Shaped Adapter – Multi-function handle for tool application and adjustment
• Molded Hard Plastic Carrying Case – Compartmentalized blue case protects all components and ensures organized, portable storage

Engine Compatibility

Supported Engine Codes:

• AXU, BAG, BKG, BLF, BLN, BLP
• Petrol engines including CBZA, CBZB, CBZC (1.2L) and BAG, BLF, BLG, BLP, BMY, BWK variants

Compatible Vehicle Models:

• Volkswagen: Polo, Golf, Golf Plus, Touran
• Audi: A3
• Skoda: Octavia
• Extended coverage: Golf, EOS, Jetta, Passat, Touran, Tiguan (1.4L/1.6L engine options)

Note: The A-8093UPG upgrade version provides enhanced capability for 1.2L CBZA, CBZB, CBZC engines and 1.4L/1.6L variants across the wider vehicle range.

Business Advantages for Resellers

• High-Margin Service Tool: Timing work commands premium labor rates; this kit enables shops to handle these jobs in-house with confidence
• Repeat Demand: Timing belt service is a recurring revenue generator—every shop performing VAG service needs reliable tooling
• Competitive Positioning: Professional timing tool kits differentiate your shop from quick-lube competitors; market this to independent VW/Audi specialists
• Durability: Precision metal construction and case protection ensure long operational life and customer satisfaction
• Bundling Opportunity: Cross-sell with other VAG timing kits to serve shops with diverse engine portfolios

Technical Specifications

Specification	Detail
Primary Use	Camshaft timing adjustment, TDC positioning
Engine Types Covered	VAG petrol: AXU, BAG, BKG, BLF, BLN, BLP and variants
Main Components	Locking plate, dial indicator, alignment bar, pins, adapter, retaining clip
Locking Mechanism	Multi-point camshaft and crankshaft positioning
Storage	Compartmentalized hard plastic case with foam inserts
Material	Hardened metal components with painted/finished surfaces
Portability	Compact molded case suitable for mobile technician use

Application Notes

• Timing Belt Replacement: Use the crankshaft alignment pin and dial indicator to establish TDC before belt removal; apply camshaft locking plate during installation to prevent accidental rotation
• Engine Rebuilds & Head Work: Lock both crankshaft and camshaft to maintain valve-to-piston timing during extended service periods
• Tension Adjustment: TDC positioning ensures accurate belt tension measurement and adjustment per OEM specifications
• Quality Assurance: Proper use prevents costly timing errors that can result in bent valves or catastrophic engine damage

Why Professional Shops Choose This Kit

Timing work is high-risk and high-reward. A single timing error results in customer comebacks, warranty claims, and reputation damage. This kit eliminates guesswork by providing mechanical locks and precision indicators that ensure every timing job is executed to OEM specification. The included carrying case means your technicians have everything they need—no improvisation, no missing tools, no delays.

---

Stock this kit for VAG specialists. Timing service is non-negotiable for any shop claiming competency on Volkswagen, Audi, and Skoda petrol engines. This is a tool that pays for itself on the first job.
