Top-down view of a blue plastic case containing four red metal timing bars, black locating knobs, and a yellow instruction label.Angled view of an open blue case with four red timing bars and black pins resting in a foam insert, plus a yellow instruction label inside the lid.

Timing Tool Set for Mercedes-Benz – Camshaft Chain Alignment and Adjustment Kit

Precision timing alignment tool set for Mercedes-Benz camshaft chain service across multiple model lines and engine variants.

Request Quote

Description

Timing Tool Set for Mercedes-Benz – Camshaft Chain Alignment and Adjustment Kit

Brief Overview

This specialized timing tool set is engineered for Mercedes-Benz camshaft chain service and timing angle adjustment across a broad range of model lines and engine configurations. The kit provides the precision locking and alignment capability required for accurate camshaft positioning during chain replacement and synchronization procedures. Whether you're servicing luxury sedans, SUVs, or performance variants, this tool set delivers the positioning accuracy that modern Mercedes engines demand. For shops working with diesel engines, consider pairing this with diesel engine timing tools with hardened steel components to expand your service capabilities.

Key Features

  • Four precision-engineered red anodized alignment bars with through-hole design for secure mounting and positioning
  • Indexed hole pattern enables repeatable, accurate camshaft locking without drift or misalignment
  • Black positioning pins provide positive locating reference points during assembly and disassembly
  • Professional-grade blue carry case with precision foam inserts protects tools and ensures shop organization
  • Instructional reference label mounted on case lid for quick procedure guidance
  • Compact, organized kit design minimizes storage footprint while maintaining accessibility

Broad Model Compatibility

C-Class & W-Series Sedans:

  • C 350 (W/S/C 204) as of 2011
  • C 400 (W 205) as of 2014

E-Class & W-Series Sedans:

  • E 300/350/400/500/63 AMG (W/S 212) as of 2011
  • E 400 HYBRID (W 212) as of 2012
  • E 300/350/400 (C/A 207) as of 2011

S-Class & V-Series Luxury Sedans:

  • S 350/500/63 AMG (W/V 221) as of 2010
  • S 500/63 AMG (C 217) as of 2014
  • S 400/63 AMG (W/V 222) as of 2013
  • S 500 PLUG-IN HYBRID (V 222) as of 2014

CL & CLS Coupe/Sedan Lines:

  • CL 500/63 AMG (C 216) 2010–2013
  • CLS 300 (C 218) as of 2012
  • CLS 350/400/500/63 AMG (C/X 218) 2011–2014

SL & SLK Roadster Lines:

  • SL 350/400/500/63 AMG (R 231) as of 2012
  • SLK 350 (R 172) as of 2011

SUV Lines:

  • ML 300/350/500/63 AMG (W 166) as of 2011
  • GL 450/500 (X 166) as of 2012
  • GLK 350 (X 204) as of 2011

G-Class & Full-Size:

  • G 63 AMG (W 463) as of 2012

R-Class:

  • R 350 BlueEFFICIENCY (W/V 251) as of 2012

Why Resellers Choose This Kit

Broad Revenue Opportunity: The compatibility list spans 15+ model lines and multiple engine families (petrol and hybrid configurations). A single kit handles timing work across your customer base without requiring multiple SKUs.

Professional Service Capability: Accurate camshaft alignment is non-negotiable on modern Mercedes engines. This tool prevents costly comebacks caused by timing drift and ensures first-pass accuracy on every job.

Organized, Durable Presentation: The precision foam-insert case protects your investment and projects professionalism to end-customers. Technicians appreciate the intuitive layout and instructional reference.

Margin-Friendly Investment: Timing service commands strong labor rates. The kit justifies itself on the first two or three jobs, making it a high-ROI addition to any shop's service toolkit.

Technical Specifications

Specification Detail
Primary Components 4 anodized red alignment bars with indexed holes; 4 black positioning pins
Material Anodized aluminum bars; hardened steel pins
Case Type Blue hard plastic carry case with precision foam insert
Carrying Handle Molded integrated handle
Case Interior Precision-cut foam with circular recesses and locating dowels
Reference Documentation Yellow instructional label affixed to case lid
Application Camshaft chain alignment and timing angle adjustment
Engine Coverage Petrol and hybrid engine families across multiple Mercedes-Benz model lines (2010–2014+)

Closing Statement

This timing tool set represents a straightforward business decision: cover the Mercedes-Benz timing service market with a single, reliable kit that your technicians will trust on high-value vehicles. The broad model compatibility and straightforward indexing design reduce training time and support calls, while the professional presentation builds customer confidence. Stock this kit and watch timing service opportunities convert into consistent, profitable labor hours.
