Two-Stage Ball Joint Removal Tool

Brief Overview

This two-stage ball joint removal tool is engineered for controlled extraction of ball joints from steering rods and suspension components. The dual forked-arm design provides stable seating behind the ball joint, while the threaded forcing screw delivers progressive pressure without shock loading. The 50-80mm adjustment range accommodates a wide variety of suspension geometries, making this an essential addition to any suspension specialist's toolkit. For applications requiring broader fitment flexibility, consider pairing this with adjustable clamping extractors or multi-size removal sets.

Key Features

• Two-stage forked arm design – Seated engagement behind the ball joint prevents slip-off and damage to connecting studs
• Progressive forcing screw – Hex nut-driven threaded bolt applies controlled, incremental pressure for smooth separation
• 50-80mm adjustment range – Accommodates mid-range suspension joints on compact and mid-sized vehicles
• Cast metal construction – Silver zinc-plated arms with steel forcing screw for corrosion resistance
• Compact working height – Operates in confined suspension cavities (85-110mm height range)
• 20mm fork opening – Optimized jaw width for standard ball joint stud diameters

Business Advantages for Resellers

This tool targets suspension specialists, independent repair shops, and fleet maintenance facilities with moderate to high suspension repair volumes. The proven two-arm separator design remains the industry standard for ball joint extraction because it eliminates the need for impact hammering or explosive separators, reducing collateral damage to suspension bushings and brake lines. Stock this alongside threaded forcing screw pullers to offer customers a complete manual ball joint removal portfolio without hydraulic equipment investment.

Technical Specifications

Specification	Detail
Tool Type	Two-Stage Manual Ball Joint Separator
Adjustment Range	50–80mm
Fork Opening Width	20mm
Operating Height (Closed)	85mm
Operating Height (Extended)	110mm
Arm Material	Cast metal, zinc-plated finish
Forcing Mechanism	Threaded screw with hex nut and washer
Connection Method	Pivot pin with threaded mounting holes
Pressure Application	Manual – progressive hex nut rotation

Why This Tool Matters

Ball joint removal without proper tooling risks suspension component failure and safety liabilities. This two-arm design eliminates guesswork—the forked arms seat positively, the threaded forcing screw applies load predictably, and the compact footprint works in tight engine bays. No hydraulic pump required, no shop floor noise, and minimal training curve for technicians.

Stock this tool and increase suspension service profitability with zero additional overhead.
